External Connectors

Line In (Blue):
This is a stereo line-level input that can be used to

record into an audio recording program.
Mic In (pink):
The mic input allows you to connect a mono microphone

for recording, videophone or voice recognition

applications.

*Note: Must use all four connectors to get the full

7.1 surround sound.

Figure 2: External Connectors

Line In

Mic In

Front Out

Rear Out

Surround Out

Center/Subwoofer

S/PDIF Out

*

*

*

*
