LA-5030 PC Card & LA-5033 PCI Adapter User Guide 2-4
2.3 54Mbps Operation and Frequency Bands
The LA-5033 PCI adapter and LA-5030 PC Card support a maximum 54Mbps data rate. The adapter
automatically shifts data rates when unable to maintain a high quality connection at 54Mbps. When
the WLAN adapter detects improved signal strength, it shifts to an increased data rate (up to the
maximum 54Mbps). Different data rate and modulation requirements exist in different bands
(standards).
IEEE 802.11a/g
Data Rate Modulation
6Mbps BPSK
9Mbps BPSK
12Mbps QPSK
18Mbps QPSK
24Mbps 16QAM
36Mbps 16QAM
48Mbps 64QAM
54Mbps 64QAM
IEEE 802.11b
Data Rate Modulation
1Mbps DBPSK
2Mbps DQPSK
5.5Mbps CCK
11Mbps CCK
