ASSEMBLY INSTRUCTIONS

Step 1 - Attach Front Stabilizer

Attach Front Stabilizer (7) to Base Frame (1) and secure with:

2 – M8 Washers (157 )

2 – M8 Spring Washers ( 118 )

2 – M8 x 90MM Allen Screws ( 123 )

Step 2

- Attach Rear Stabilizer

Attach Rear Stabilizer (8) to Base Frame (1) and secure with:

2 – M8 Washers ( 157 )

2 – M8 Spring Washers (118)

2 – M8 x 90MM Allen Screws (123 )

Step 3 - Install Seat Lock Handlebar

Attach the Seat Lock Handlebar ( 6 ) onto the Seat Lock handlebar base ( 61 ) using:

2 – M5 x 20MM Screws ( 139 )

Step 4 - Install Seat

Attach Seat ( 19 ) to Seat Carriage Frame (56) using:

4 – M8 Washers ( 157 )

4 – M8 Spring Washers ( 118 )

4 – M8 x 20MM Allen Screws ( 122 )
