Complete parts list – Smooth Fitness SB4 User Manual
Page 19
COMPLETE PARTS LIST
NO. DESCRIPTION QTY
NO. DESCRIPTION QTY
85
COMPRESSOIN SPRING - SMALL
1
126
ROUND ALLEN HEAD BOLT (M5 x 15mm)
2
86
COMPRESSOIN SPRING - BIG
1
127
ROUND ALLEN HEAD BOLT (M6 x 12mm)
4
87
TENSION SPRING FOR SEAT RAIL
1
128
ROUND PHILIPS HEAD SELF TAPPING (4 x 20mm)
11
88
TENSION SPRING - SMALL
1
129
ROUND PHILIPS HEAD MACHINE (M5 x 15mm)
2
89
COMPRESSION SPRING
1
130
SCREW M5 x 15mm
2
90
UPPER COMPUTER WIRE
1
131
SCREW M5 x 10mm
13
91
LOWER COMPUTER WIRE
1
132
SCREW M5 x 25mm
4
92
UPPER HAND PULSE WIRE
1
133
HEX HEAD BOLT(M6 x 18mm)
4
93
MIDDLE HAND PULSE WIRE
1
134
HEX HEAD BOLT (M6 x 70mm)
1
94
LOWER HAND PULSE WIRE
1
135
HEX HEAD BOLT (M8 x 16mm)
2
95
DC WIRE
1
136
HEX HEAD BOLT (M8 x 25mm)
1
96
SENSOR WIRE
1
137
HEX HEAD BOLT (M8 x 32mm)
1
97
SERVO MOTOR
1
138
HEX HEAD BOLT (M8 x 52mm)
1
98
6001 BEARING
1
139
SCREW M5 x 20mm
2
99
6300 BEARING
1
140
SCREW M6 x 15mm
4
100 6000 BEARING
1
141
SCREW M6 x 25mm
2
101 6003 BEARING
2
142
SCREW M6 x 30mm
2
102 6203 BEARING
2
143
SCREW M8 x 40mm
1
103 C17 C CLIP
2
144
SCREW M5 x 20mm
4
104 C10
C
CLIP
10
145
ROUND PHILIPS HEAD SCREW (M3 x 35mm)
4
105 C12
C
CLIP
1
146
ROUND PHILIPS HEAD SCREW (M4 x 10mm)
2
106 3/8"
WH
NUT
2
147
ROUND PHILIPS HEAD SELF TAPPING (4 x 10mm)
4
107 NYLOC
NUT
(M6)
8
148
ROUND PHILIPS HEAD SELF TAPPING (6 x 12mm)
3
108 NYLOC NUT (M8) - BLACK
5
149
ROUND PHILIPS HEAD SELF TAPPING (#10-32)
12
109 NYLOC NUT (M8)
1
150
Hex Head Shoulder Bolt (M8 x 25mm)
2
110 NYLOC
NUT
(M10)
8
151
ROUND PHILIPS HEAD SELF DRILLING (M8 x 16mm)
4
111 HEX TAPER NUT ( 3/8" )
1
152
FLAT WASHER (ID-5 x OD-14mm)
2
112 HEX TAPER NUT ( M3 )
4
153
FLAT WASHER (ID-6 x OD-16mm)
1
113 HEX TAPER NUT ( M6 )
1
154
FLAT WASHER (ID-6 x OD-16mm)
4
114 HEX TAPER NUT 3/8"-16UNC
1
155
FLAT WASHER (ID-8 x OD-16mm)
6
115 SPRING WASHER M6
2
156
FLAT WASHER (ID-8 x OD-16mm)
1
116 SPRING WASHER M6
4
157
FLAT WASHER (ID-8 x OD-16mm)
22
117 M8 SPRING WASHER - BLACK
4
158
FLAT WASHER (ID-8 x OD-22mm)
1
118 M8 SPRING WASHER
22
159
NYLON WASHER
1
119 ROUND ALLEN HEAD BOLT (M8 x 15mm)
9
160
NYLON WASHER
2
120 ROUND ALLEN HEAD BOLT (M8 x 15mm)
14
161
FLAT WASHER 10.2*18*3T
8
121 ROUND ALLEN HEAD BOLT (M8 x 20mm)
2
162
BLIND BOLT
3
122 ROUND ALLEN HEAD BOLT (M8 x 20mm)
4
163
T SHAPE WASHER
2
123 ROUND ALLEN HEAD BOLT (M8 x 90mm)
4
164
ADAPTOR
1
124 ROUND ALLEN HEAD BOLT (M4 x 12mm)
2
165
NYLOC NUT
1
125 ROUND ALLEN HEAD BOLT (M5 x 10mm)
8
18
