SVA CRR-1106H - Manual

Specifications
Vandal Proof / Weatherproof Camera
CRR-1106H
Features
SVA Group (USA) Inc.
350 Ranger Ave, Suite A
Brea, CA 92821
Tel: 714-646-7024
Fax: 714-993-3371
1-888-8-ASK-SVA
www.sva-usa.com
Dimensions
MODEL
Signal System
Image Sensor
NO. of Effective Pixels
Horizontal Resolution
Minimum Illumination
S/N Ratio
Average Life
View Angle
Lens
IR-LED
Working Distance
Vandalproof criterion
Video Output
Power Supply
Operation Temperature
Body
Weight
PAL/NTSC
1/3" SONY CCD(Color)
PAL:752(H)X582(V);NTSC:768(H)X494(V)
540 TV Lines
0LUX LED ON
More than 52dB
20000hrs
60°
3.5~8mm
48 PCS LED;850nm
195’
IP65
Composite Video Output(1Vp-p 75ΩTerminated)
DC 12V(+/-10%)
-20°C to +50°C
Aluminum
TBD
The CRR-1106H color long range varifocal IR camera
is designed for high risk applications. The traditional
styling makes it ideal for use in situations where an
instant deterrent or heavy duty camera is required. It also
offers high resolution 540 TVL images from its Sony HQ1
CCD sensors and 3.5~8mm Varifocal Lenses which allow
easy selection of the optimum viewing angle required
during installation. It will also provide images in complete
darkness up to 130 feet.
Designed for internal/external use this model can be wall
mounted with a cable managed bracket and removable
sun/rain shield.
CRR-1106H
