SVA PTZ Camera CZC-1301C - Manual

Specifications
PTZ Camera
CZC-1301C
Features
SVA Group (USA) Inc.
350 Ranger Ave, Suite A
Brea, CA 92821
Tel: 714-646-7024
Fax: 714-993-3371
1-888-8-ASK-SVA
www.sva-usa.com
Connections
MODEL
TV System
Image Sensor
NO. of Effective Pixels
Horizontal Resolution
Minimum Illumination
S/N Ratio
Pan/Tilt Speed
Zoom
Lens
White Balance
Focus
Protocol
Presets
Power Supply
Control
Body
Weight
NTSC/PAL
1/4" SONY Super HAD CCD
768(H) x 494(V) (NTSC)
480 TV Lines
1.0 Lux (Day) / 0.001 Lux (Night)
More than 48 dB (AGC off)
Preset : 300°/sec; Manual : 0.1° ~ 300°/sec; Swing : ~ 60°/sec
x22 Optical Zoom, x10 Digital Zoom
f=3.9 ~ 85.8mm
Auto / Manual / Indoor / Outdoor
Auto / Manual
Pelco-P, Pelco-D
64
AC24V
RS-485 (Max. 99 unit)
Aluminum
5.5 lbs
CZC-1301C
● CCD Sensor : 1/4" Super HAD CCD
● Zoom Magnification : x22 Optical Zoom, x10 Digital
Zoom(combined x220 Zoom)
● Day & Night Function
● Max. 300°/sec high speed Pan/tilt Motion
● Using Vector Drive Technology, Pan/Tilt motions are accomplished
in a shortest path. As a result, time to target view is reduced
dramatically and the video on the monitor is very natural to watch.
● Max. 64 sets of position and zoom magnification are designated
and stored as Preset. For each Preset, additional information such
as Dwell time (pause time in Group action when camera reaches
to a certain Preset position), Alarm action and area Label can be
assigned independently to meet to your requirements.
● With RS-485 communication, max. 99 of cameras can be controlled
at the same time
● Pelco-D or Pelco-P protocol can be selected as a control protocol
in the current version of firmware.
● OSD menu is provided to display the status of camera and to
configure the functions interactively.
● This model is structured to meet outdoor environment. To this end,
Fan and Heater are built in the housing and weatherproof
environmental structure is designed to meet international standard
IP66.
