28
Key operation example
Ctrl + Menu : Press and hold down Ctrl Key and press Menu Key
1 + Cam : Press 1 Key, Cam Key sequentially
Ctrl + Joystick : Press and hold down Ctrl Key while manipulate Joystick Handle
Enter + Joystick : Press and hold down Enter Key while manipulate Joystick Handle
3.3.1 Keys for Dome camera
Function Key Label Descriptions
1,2, ... 9,0 1,2, ... 9,0
Camera selection with Cam key.
Function number selection with function keys.
(e.g., 1+Cam, 3+Tour, 5+Scan, 6+Prst)
Camera CAM
Displays the selected camera on the spot out of the multiplexer and allows the
camera to be controlled by the keyboard controller, if the selected camera is a dome
camera.
Full MAIN Camera No. 1~16+Main will display the selected camera full screen
Cancel ESC
Cancels current inputs.
Exits from currently running functions or menu, error status, etc.
Alarm ALRM
Disregards all currently activated alarms and turns off the beep temporarily. If alarm
is activated again within the programmed hold time, the timer will restart and beep
again.
Relay ON ON Relay No. 1~4+ ON will activate the selected relay.
Relay OFF OFF Relay No. 1~4+ OFF will disable the selected relay.
Previous PREV Allows the previous dome camera to be controlled manually.
Next NEXT Allows the next higher number dome camera to be controlled manually.
Home HOME
Immediately calls Home function.
Deletes selected value or function in programming mode
Global GLBL
Sends all cameras to preset (e.g., 1, 2… 55 + Enter/Glbl).
888+Enter/Glbl: Night shot mode, 999+Enter/Glbl: Normal mode
Call Preset
position
PRST
Pressing Prst will bring up the preset programming menu.
Recalls preset; e.g.; 1, 2… 31… 240 + Prst
In the preset or tour programming mode, the operator can review the exiting preset
(selected by cursor) by pressing this key.
Tour TOUR
Pressing Tour will bring up the tour programming menu directly
Recalls programmed presets or functions sequentially. (e.g., 1 ~ 8+Tour)
Pattern PTRN
Pressing Ptrn will bring up the pattern programming menu directly.
Repeats the selected pattern of the current dome camera. (e.g., 1 ~ 4+Ptrn)
Auto Scan SCAN
Pressing Scan will bring up the Auto Scan programming menu.
Calls Auto panning function (e.g., 2+Scan repeats Auto Scan 2).
Configuration MENU
Enters programming menu.
Ctrl+Menu will invoke Keyboard set up menu
Program PGM
No.+Pgm+Prst will store current view as a preset directly.
No.+Pgm+Tour will open programming menu
No.+Pgm+Scan will open programming menu
Control CTRL
Ctrl+Joystick : In a programming mode (Preset, Pattern, Scan, Privacy….) the
joystick operates as if in the normal control mode.
While pressing and holding down the Ctrl key, all movements of the joystick will start
recording when in the pattern programming menu.
Ctrl+Joystick:, In normal operation mode, manual speed of the joystick control will
be operated in turbo mode. (Max. speed = 380
º /sec)
Enter ENTER
Completes entering data for the password or title
ENTER+Joystick : Direction key in DVR remote mode or Mux ( PTZ, Mouse,
Cursor)
