Sony RM-TP504 - Manual (Page 8)

8 GB
Parts description (continued) wj Numeric buttons (1–9, 0/10)*
If you selected tuner:
Use with “SHIFT” button to select tuner
preset station numeric input during
DIRECT TUNING or MEMORY mode.
If you selected CD player, VCD player,
LD player, MD deck, DAT deck:
Press to select track numbers. 0/10 selects
track 10.
If you selected TV, VCR, SAT:
Press to select channel numbers.
wk ENTER button
After selecting a channel, disc or track using
the numeric buttons, press to enter the
valve.
wl ALT button
Press to change remote key function to
activate those buttons with orange printing.
e; Operation buttons*
The following table describes the
component operated by each button and the
function of the buttons. See the table on
page 9 for information on the buttons that
you can use to control each component.
Button(s) Function
./> Skips tracks
m/M Fast forwards or rewinds.
Searches tracks in the forward
or backward direction
N Starts play. (Starts play on the
front sides of the cassette.)
X Pauses play or recording or
starts recording when the
component is in recording
standby.
x Stops play.
ea USE MODE button
Press to set up the remote.
Note
The MPX/DUAL and 12 buttons are not available.
* The function of these buttons switch automatically
each time you press the function buttons (3).
Depending on the component, the above operation
may not be be possible or may operate differently
than described.
N X
m M
. >
-
VIDEO1 VIDEO2
USE MODE
SYSTEM STANDBY SLEEP
AV1 AV2
M1 M2
2ND
TV ?/1 AV ?/1
VIDEO3 DVD/LD
TV/SAT TAPE MD/DAT CD/SACD
TUNER PHONO MULTI CH SOURCE
SHIFT
TOP MENU/
GUIDE AV MENU
MUTING
MASTER
VOL
DISPLAY
TV VOL TV CH
WIDE ON SCREEN
TV/
VIDEO
MAIN
MENU
RETURN/EXIT
D.TUNING DISC ALT
ANT CLEAR SEARCH MODE
TEST
TONE PRESET
1 2 3
4 5 6
7 8 9
0/10 >10/11 12
AUTO DEC
SUBTITLE ENTER
MODE
AUDIO
SWAP/
ANGLE
JUMP/
TIME
PRESET/
CH/D.SKIP
MPX/
DUAL
ANALOG
DIRECT 2CH
SOUND FIELD
x
?/1
P
O
f
F
G g
wk
wj
wl e;
ea
