5. When the correct size is determined, place the
screw through the speaker post and attach to the
rear of the speaker enclosure. If the screw does not
tighten properly, use the M5 x 1/8" plastic washer
to tighten it up.
Key Hole Mounting
1. If your speaker has a factory key hole design, you
will use the 5/8"-32 x 5/8" machine screws in
combination with the key hole nut.
2. Loosely pre-assemble the mounting post with the
5/8"-32 x 5/8" machine screw and key hole nut, see
Figure 4
below. Be sure the key hole nut is installed
with the knurled (rough) edge toward the host.
M5 x 1/8"
Plastic Washer
5/8"-32x5/8"
Machine Screw
5/8"-32x5/8"
Machine Screw
Mounting Post Keyhole
Back Speaker
Figure 4
