Assembly, 306 x4, 304 x4 – Smooth Fitness 835 User Manual
Page 16
16
835i TREADMILL
ASSEMBLY
STEP 2: Attach the Handle Bars
(1). Take out right handle bar from carton, connect
handle button wire (223).
(2). Attach the Right and Left Handle Bar and secure using the M8x15mm Allen
Head Bolt (306) with M8 Flat Washer (304).
306 X4
304 X4
Tighten all bolts and fasteners now
223
223
Speed
Incline
