TECHNICAL FEATURES HT200 HT200 SWA HT250 HT200 DMF HT300 PLUS
LIGHT ENGINE
DLP TM Type: Proprietary sealed optical engine
based on 1 DMD TM Chip. Sealed Housing • • • • HD2 chip
Resolution (pixel) Dual mode:800 x 600
800 x 600 pixels 800 x 600 pixels 1024 x 768 pixels pixels and 848 x 480 pixels True 16:9 (1280 x 720 pixels)
Lens: High quality, high resolution Super wide angle fixed High quality, high resolution High quality, high resolution High quality, high resolution
optics with both motorised lens with manual focus adj optics with both motorised optics with both motorised improved optics for higher
zoom and focus adjustments zoom and focus adjustments zoom and focus adjustments contrast and better black level
with both motorised
zoom and focus adjustments
Lamp power Consumption & Life Time: (6000 hours*) 120W 120W 120W 120W 120W
INSTALLATION
Optical Keystone Adjustment – lens shift: +/-10° n.a. +/-10° +/-10° +/-10°
Digital Keystone Adjustment: +/-17° vertical n.a. +/-17° vertical +/- 13° vertical, +/- 13° vertical,
+/-10°horizontal +/-10°horizontal
Picture Size: 50-250 inches diagonal 50-150 inches diagonal 50-250 inches diagonal 50-250 inches diagonal 50-300 inches diagonal
Aspect Ratio: normal, anamorphic, • • • plus panoramic plus panoramic
letterbox plus 3 custom-user adjustments and pixel to pixel and pixel to pixel
ELECTRONICS
Horizontal & Vertical Scan Freq.: 15 – 80KHz /
48 – 100Hz (max horizontal freq. corresponding
to UXGA, 60Hz)
• • • • •
Video Standards and Graphic Resolutions:
PAL B,G,H,I,M,N,60, SECAM, NTSC 3.58 & 4.43
automatically selected, HDTV: ATSC (480p, 720p, 1080i)
• • • • •
PC Graphic standard: VGA, SVGA, XGA, UXGA
(1600x1200 pixel) • • • • •
DCDi by Faroudja n.a. n.a. n.a. • •
Contrast Ratio (full On / full Off): >600:1 >600:1 >600:1 >600:1 >1800:1
Colour Temperature: 3 preset colour temperatures
plus a RC user adjustment acting directly on each
colour (Red, Green and Blue).
• • • • •
Special Video Adjustment:
Luma-Choma Delay, Adjustment by OSD • • • • •
GENERAL SPECIFICATIONS
Control: Control Software can be upgraded via
RS232 serial interface • • • • •
Power Consumption: 170W max 170W max 170W max 170W max 180W max
Mains Voltage Range (48/62Hz): 120 - 240Vac, +/- 10% 120 - 240Vac, +/- 10% 120 - 240Vac, +/- 10% 100 - 240Vac, +/- 10% 100 - 240 Vac, +/- 10%
Weight: 11 lbs (5.0 Kg) 11 lbs (5.0 Kg) 11 lb (5.0 Kg) 11 lbs (5.0 Kg) 12.8 lbs (5.8 Kg)
Cabinet Dimensions (W x H x D): 13,8”x6,6”x12,5” 13,8”x6,6”x12,5” 13,8”x6,6”x12,5” 13,8”x6,6”x12,5” 13,8”x6,8”x12,5”
(350x167x318 mm) (350x167x318 mm) (350x167x318 mm) (350x167x318 mm) (350x173x318 mm)
(*) Lamp life: the hours quoted have been calculated under strict test conditions. Misuse or improper use may alter it.
Screen size (diagonal)
vs. Throw Distance
HT200 & HT200 DMF (4:3 mode)
Throw Ratio: 2.3 - 3.1:1
60” – min 110” – max 154”
80” – min 147” – max 205”
100” – min 184” – max 256”
HT200 DMF (16:9 mode)
Throw Ratio: 2.2 - 3.0:1
60” – min 113” – max 154”
80” – min 150” – max 205”
100” – min 188” – max 256”
HT200 SWA
Throw Ratio: 0.8:1
60” @ 38”
80” @ 52”
100” @ 64”
HT250
Throw Ratio: 2.2 - 3.0:1
60” – min 106” – max 144”
80” – min 141” – max 192”
100” – min 100” – max 240”
HT300 PLUS (16:9 mode)
Throw Ratio: 1.8 - 2.4
60” – min 94” – max 130”
80” – min 126” – max 173”
100” – min 157” – max 217”
Inputs/Outputs
1 Composite video via RCA connectors
1 S-VHS via mini Din 4 pin
1 RGBHV via Dsub 15 (PC input)
1 x RGBS/YCrCbS via 4xRCA connectors
1 Remote Input Interface, EVC type,
Standard VESA
1 x RS232 on Dsub 9 pins connector
1 x DVI on DVI-D input (HT300PLUS only)
1 x jack 12V power output,
active when the projector is ON
1 x jack 12V power output,
active when 16:9 format is selected
(max 12V power output 100 mA)
Certifications
Safety – in compliance with EN 60950/UL1950
Vibration – in compliance with IEC 68-2-6
Emission – in compliance with EN 55022
class B/150KHz – 30MHz
Recyclable packaging.
Long throw ratio for a real cinema view
Supplied Accessories
AC power cords (EU, UK and USA), length 3m.
User standard remote control with batteries.
Installation and user manual.
Optional Accessories
Remote Imput Interface (RII) Including
special connection cable between the projector
and the RII, 30 ft (10 m) long
Ceiling bracket & GRAND CINEMA style
floor/ceiling stand
