Shoprider UL7WR - Manual (Page 19)

8/16/2005 19
Specifications
Table 2
Jiffy (UL7WR) Jiffy 11 (UL7WR11)
Overall Dimensions: L 1 x W x H 37” x 19” x 33” 37” x 21” x 33”
Number, Size of Front Tires 2, 6 inches 2, 6 inches
Number, Size of Rear Tires 2, 8 inches 2, 8 inches
Total Weight of Unit 100 lbs 104 lbs
Maximum User Weight 225 lbs 250 lbs
Battery Capacity 12v - 12Ah x 2 12v - 12Ah x 2
Charger Off-Board, (2amp) Off-Board, (2amp)
Output Power of Motor .45 hp .45 hp
Ground Clearence 2.25 inches 2.25 inches
Seat Floor Height 19, 20, 21in 19, 20, 21in
Maximum Speed 3 mph 3 mph
Safe Climbing Angle, Maximum
Single User Weight Refer to
Figure 8 Refer to
Figure 8
Range 2 9 mi 9 mi
Turning Radius 27.5 inches 28.5 inches
As a part of our ongoing product improvement initiative, Shoprider
reserves the right to change specifications and design without prior
notice. All specifications and dimensions are approximate.
1 Includes the anti-tip wheel.
2 The actual driving range varies with the factors shown below:
1. The weight of the user
2. Ground surface condition
3. Battery condition
4. Type of charger
5. Ambient temperature
6. Driving style
7. Terrain
