Disassembling/Transporting the Shoprider Jiffy Powerchair
Follow these simple guidelines for
disassembly:
1. Park the Powerchair on a
level surface
2. Ensure the wheels are
locked in drive mode (Fig 3)
3. Fold up footplate
4. Unplug VSI from rear of unit
5. Remove battery pack from
rear of unit
6. Remove seat by unscrewing
the tightening knobs and
lifting seat upward and off
2
3
4
5
6
Figure 6
1
2
3
4 5
6
Figure 7
