Hooking up the system – Sony TC-TX5 User Manual
Page 4
TC-TX5 3-858-049-11 (1).EN
4
Hooking up the system
Do the following procedures 1 to 3 to hook up your system using the supplied cords.
Connect the AU BUS connecting
cord to the AU BUS connectors until
it clicks.
Connect the audio connecting cords
to the jacks of the same colour.
1
Connect the mains lead to a wall
outlet.
3
2
1
2
1
2
3
TC-TX5 rear panel
DHC-MD5 rear panel
