– 8 –
4 Place the ribbon cartridge in the direction shown
in figure and press it down to load it. If loading
of the ribbon cartridge is not satisfactory, press
down the cartridge while rotating the ribbon feed
knob in the direction of the arrow.
5 Turn the ribbon feed knob of the ribbon cartridge
in the direction of the arrow to remove slack in
the ribbon.
6 Close the Auto Cutter.
7 Mount the cover by reversing the procedure
outlined in step 2 above.
Note: When removing the ribbon cartridge, raise
the A section and then remove it by holding
the B section as shown in figure.
A
B
3 Lift up the auto cutter and put it in a vertical
position, as shown in figure. Auto cutter
Print head
Ink ribbon
Auto cutter
Ribbon feed
knob
Notched part
Ribbon
cartridge
