Sima Products XL-8 - Manual (Page 7)

Page 7
5. (Fig. 6) shows both style pumps for the XL Theater
System. The top picture shows the pump included with the
8’ foot model and below it shows the pump for the 12’
model. Both style pumps are marked with an “inflation” port
for blowing up the frames.
6. Attach the inflator hose to the pump inflation port marked
“Inflate”. (Fig. 7)
7. Attach the other end of the AC pump hose to one of the air
valves on the frame by pushing the end firmly into the
inflation port. None of the attachments should be used on
the end of the hose. Be sure to close the unused valve so
it doesn’t leak air while inflating the screen. (Fig. 8)
8. Turn the pump to the “on” position. (On Switch is located
on the face of the pump).
NOTE: THE FRAME SHOULD NOT TAKE MORE THAN 5
MINUTES TO INFLATE. MAKE SURE THE PUMP ISN’T
IN USE FOR MORE THEN 15 MINUTES. IT CAN
OVERHEAT!
WARNINGS:
• Never attempt to disassemble or close the
openings while pump is operating.
• Never leave pump unattended while in use.
• Never allow sand, small rocks etc… to be
sucked into the inflation or deflation port while
operating.
• Do not use under wet conditions – keep away
from water
• Never look into or point the inflate port toward
your eyes while pump is operating.
• The power supply cord cannot be replaced. If
the cord is damaged, contact Sima customer
service for a replacement pump.
• Keep away from children
• When used outdoors or near water, use a
properly grounded GFI outlet.
Fig. 6
Fig. 7
Fig. 8
