9
PREPARATION
10 : 0
1
1
Projection lens can be moved up and down with motor-driven lens shift function. This function makes it easy to
provide projected image where you want. U/D ratio can be adjusted 10 : 0 ~ 1 : 1 (refer to figure below.). Refer
to P 20 for operation.
Highest (10 : 0) Lowest (1 : 1)
POSITIONING PROJECTOR
LENS SHIFT ADJUSTMENT
This projector is designed to project on a flat projection
surface.
ROOM LIGHT
Brightness in a room has a great influence on picture
quality. It is recommended to limit ambient lighting in
order to provide best image.
SCREEN
Before setting up a projector, install Projection Lens on
Projector.
1. Before installation, check where a projector is used and
prepare suitable lens. For specifications of a Projection Lens,
contact sales dealer where you purchased a projector.
2. For installation, refer to installation manual in the optional
lens.
LENS INSTALLATION
COVER CAP
When install the lens, remove the cover cap in the projector.
NOTE;
