USB-101 User manual Getting Started
Page 6
Front panel drawings
Front panel controls
1. Here/There
USB device
indicators - indicate that
a recognized device is
connected to the Here or
There port and is being
viewed on the display
2. HERE/THERE button
Retreats through the active
menu tree or toggles the
display between Here and
There devices
3. Scroll wheel
To scroll between menu
options
4. SELECT
button
To select menu options
and view file information
5. SEND button
To execute file transfers
1
2
3
4 5
