6. GENERAL SPECIFICATIONS
Printing method
Serial impact dot matrix printing,
9 wires
Number of print columns 40 columns, 12 CPI
Print speed
Approx. 2 lines/sec
Print direction
Bi-directional
Line spacing
1/6 inch
Paper feed method
Friction Feed or Sprocket-feed
Paper feed speed
Approx. 12 lines/sec
Character set
ASCII
96
Special
64
Block graphics*
64
Katakana (Japanese)
64
IBM Special
83
IBM Block graphics*
50
Download
10
Font configuration
Ordinary characters
5
×
9 dots
Block graphics*
6
×
6 dots
(6
×
8 dots)
* Graphic Feed Not Available
Character size
2.42 (H)
×
1.71(W) mm
Dot spacing
0.35 (H)
×
0.35 (W) mm
Print area
84.3 mm
Print Buffer
Approx. 1.5 KB
Interface
Parallel Interface (Centronics compatible)
Peripheral drive
2 outputs (each 1A max. at 12V. Both cannot
operate at the same time.)
External dimensions
(Printer)
202(W)
×
200(D)
×
98(H) mm
(without paper holder, DC Power Connector)
(Power supply unit)
60(W)
×
120(D)
×
36(H) mm (without AC cable)
Weight
(Printer)
Approx. 1.9 kg
(Power supply unit)
Approx. 0.4 kg (without AC cable)
Power supply unit
Four supplies available with following ratings
Input
Output
AC 100 – 240 V
DC 12.0 V
±
5%
47Hz – 63 Hz
0.8 A Max
2.0 A
