18 Iss 2
Tiller control functions
Photo 5
Top Facia Panel
Handle Bars
Throttle
Lever
Control
Hand Controls
All of the drive controls for the scooter are to be found on the Tiller Control
Box (Photo 5).
The Pre-set Speed Knob
Turning this knob to the left, reduces your available maximum speed.
Turning it to the right, increases the available maximum speed.
The Battery Gauge
This gives an approximation of battery charge.
The gauge is marked from “E” empty, to “F” full. For extra clarity there is a
coloured graduated scale ranging from RED, (E) through YELLOW to
GREEN, (F).
As the scooter moves over differing terrain, the Battery Gauge will dip up
and down, this is normal. For a more accurate indication, stop the scooter
and note the reading.
GREEN indicates ready for use.
YELLOW indicates batteries to be charged as soon as possible.
RED indicates charge batteries imediately.
TIP:
If you find that your battery gauge has gone into the red whilst you are out
and about, you can increase the remaining range of your scooter by
reducing your maximum available speed, but you MUST charge your
scooter as soon as you can.
On/Off Key
Vertical = Off
Horizontal = On
Battery
Gauge
Horn
Speed
Control Knob
