CONTROLs AND CONNECTIONs
FRONT VIEW
MENU
6
15
10 7 2 1 4 3
5
9 8
11 12 13
14
16
This section provides information about the controls and
connections available on your Audio Server.
DIsC TRAY
Discs should be inserted with the label side up.
OPEN/CLOsE button
Pressing the OPEN/CLOSE button opens the disc tray.
Place a compact disc on the tray with the label side
facing up. Press the button again to close the tray.
OUTPUT button
Press the MENU button to display the Menu screen.
ACTION buttons
Action buttons allow you to perform specific operations
dependent on the current menu screen. For more
information on using the action buttons, refer to The
Front Panel Interface chapter on page 27.
DIsPLAY
The display shows information about the music
available on the unit, the status of the Audio Server (for
instance if the unit is currently playing), and the current
configuration of the unit.
sELECT button
Selects the option currently visible on the display.
NAVIGATION buttons
The navigation buttons allow you to move up, down, left
or right through the menus shown on the display.
N OUTPUT button
This button is used to select the current audio output.
d / f button
When the button is pressed briefly during playback, play
restarts at the beginning of the current track. A second
brief press moves to the beginning of the previous track.
When the button is held for a longer period of time the
music will rewind at high speed.
c / e button
When the button is pressed briefly during playback, play
restarts at the beginning of the next track. When the
button is held for a longer period of time the music will
fast forward at high speed.
h PAUsE button
Press the pause button to interrupt playback temporarily.
a PLAY button
Press the play button to resume playback if the music has
been stopped or paused.
g sTOP button
Press the stop button to halt playback on the current
audio output.
sTANDBY
Press the standby button to turn your Audio Server off,
press again to switch your Audio Server back on.
REMOTE sENsOR
This window receives signals transmitted from the
remote control unit.
ONLINE
The online indicator is illuminated when the modem is
active.
