Siemens CIELO User Manual
Page 17
17
Safety Instructions for hearing systems with audio input
The audio input may be connected to line-operated equipment
only if the equipment fulfils the safety requirement IEC 65 / DIN
VDE 0860.
Before the audio shoe can be connected to the hearing system
the following steps have to be fullfilled:
1. Open the battery compartment
2. Open the audioshoe cover
3. Close the battery compartment
With the connected audio shoe the battery compartment
switch is disable and the hearing system only can be switched
off with the push button.
Take the audio shoe and hook
the two nibs into the two small
recesses of the hearing system
housing. Slide the audio shoe
to the inner side of the hearing
system housing until it snaps
into the end position.
Attaching the audio shoe
To remove the audio shoe, slide
the audio shoe in the opposite
direction.
Removing the audio shoe
240605405_Siemens_CIELO_BTE_GB 12.12.2005 12:32 Uhr Seite 17
