Controls Operation
STARTING THE ENGINE
NOTE: The snow thrower engine is designed to operate
at co/d temperatures. Avoid operating the snow thrower if
air temperature is 40” C or warmer since engine may
vapor lock and stop running after a time. Engine
be difficult to start in warm weather.
Electric Starting Steps
Note: The electric starter is designed to operate on
AC household current, using power cord supplied with
electric start snow thrower. When using power cord,
match wide blade to wide slot of receptacle.
1. engine key in switch and turn key to the ON
position.
2. If engine is cold, move choke control lever to the ON
position. (Do not choke a warm engine).
3. Push the Primer Button two times if engine is cold.
(Do not prime a warm engine.)
4. Plug power cord for starter into receptacle on starter
switch, then plug other end into a AC house-
hold receptacle. DO NOT use an extension cord with
the electric start power cord supplied.
receptacles when plugging cord into receptacle.
5. Push starter button to crank engine. DO NOT crank
engine for more than a total of 15 seconds without
allowing electric starter to cool for
minutes before
additional cranking is attempted. Electric starter can
be severely damaged if recommended starter operat-
ing limitations are not observed.
NOTE: Do not push primer button while engine is
Manual (Recoil) Starting Steps
Insert engine key in switch and turn key to the ON
position.
2. If engine is cold, move choke control lever to the ON
position. (Do not choke a warm engine).
3. Push the Primer Button two times if engine is cold.
(Do not prime a warm engine.)
4. Grasp starter rope handle and slowly pull out rope
until resistance is felt. Allow rope to rewind slowly,
then pull rope out rapidly to start engine. Let rope
return slowly to starter.
NOTE: If engine does not start after three pulls,
push primer bulb once and again pull starter
rope.
5. After engine starts and gradually warms up, move
choke lever to the OFF position. Be prepared to
move choke lever to the ON position if engine falters
during warm up.
6. Allow engine to warm up before beginning snow
thrower operations. The engine will operate at full
throttle when thoroughly warmed up.
7. To stop engine, turn Engine Key to the OFF position.
STOPPING THE ENGINE
1. Release the Auger Control.
2. Turn Engine Key to the OFF position.
NOTE: Always disconnect power cord from
6. Release starter button when engine starts and
ally move choke lever to the OFF position.
household receptacle first, then unplug from
starter switch.
7. Disconnect power cord from household receptacle
and then from starter switch on snow thrower. Store
cord in a dry, convenient place.
or’making any adjustments or
3. Remove the key from the switch if you are leaving the
operating position or will be making adjustments or
If you be storing the unit for the season, see the
repairs. (NOTE: Allow the unit to before storina
STORAGE section for instructions on properly preparing
the unit for long-term storage.
8. To stop engine, turn Engine Key to the OFF position.
