20 734348 Rev C
How Do I Connect Ethernet Network Devices?
How Do I Connect Ethernet Network Devices?
Connecting Ethernet Devices
You must connect your Ethernet devices for use with the cable modem. Professional
installation may be available. Contact your local service provider for further
assistance.
The following diagram illustrates one of the various Ethernet network connection
options that are available to you.
USB
CABLE
POWER
ETHERNET
1/2 TELEPHONE
REBOOT EMT
A
2
Power
Cord
Cable-Ready TV,
VCR, or Set-Top
Converter
PC Ethernet
Cable
RF
Cable
RF
Cables
Cable
Splitter
T11717
BYPASS VOLñ VOL+ CH+
CHñ MENU GUIDE INFO A/B POWER
Home Telephone Wiring
Line 1
Home Telephone Wiring
Line 2
WARNING:
Hazardous electrical voltages can be present on any connected wiring.
Ethernet wiring and connections must be properly insulated to prevent
electrical shock. Disconnect power from the cable modem before attempting
to connect to any device.
To avoid personal injury, follow the connection steps in the exact order
shown.
CAUTION:
To prevent possible damage to the equipment, disconnect any other service
before connecting your cable modem to other devices.
Read the warnings and caution on this page. Then, follow the installation procedures
later in this guide to ensure proper cable modem operation when connecting
Ethernet network devices.
