Area used Requirements for emitted interference interference immunity
Industrial EN 50081-2: 1993 EN 55022 Class A: 1998 EN 50082-2: 1995
Printed in Germany
Notes on CE identification
The devices comply with the regulations
of the following European directive:
89/336/EEC
Council Directive on the harmonisation
of the legal regulations of member
states on electromagnetic compatibility
(amended by Directives 91/263/EEC,
92/31/EEC and 93/68/EEC).
The product can be used in the residential
sphere (residential sphere, business and trade
sphere and small companies) and in the
industrial sphere. The precondition for compliance with EMC limit
values is strict adherence to the construction
guidelines specified in this description and
operating instructions.
4. Technical data
General data
Operating voltage DC 9.6 to 57.6 V safe extra-low voltage (SELV) (redundant inputs decoupled)
Current consumption typ. 160 mA at 24 VDC
max. 190 mA at 24 VDC
Overload current protection at input non-replaceable thermal fuse
Dimensions W x H x D 47 mm x 135 mm x 111 mm 1.9 in x 5.3 in x 4.4 in
Weight 230 g 0.51 lb
Ambient temperature 0 ºC to + 60 ºC 32 ºF to + 140 ºF
Storage temperature - 20 ºC to + 80 ºC -40 ºF to + 176 ºF
Humidity 10% to 90% (non condensing)
Protection class IP 20
Laser protection Class 1 conform to EN 60825
Radio interference level EN 55022 Class A
Warning!
This is a Class A Equipment. This equipment may cause radio interference if used in a residential
area; in this case it is the operator´s responsibility to take appropriate measures.
Interference immunity EN 50082-2
Network size
Transition TP port ↔ F/O port and F/O port ↔ TP port
Propagation equivalent 2 x 42 BT = 84 BT (1 BT = 10 ns)
TP line length (TP port ↔ TP port)
Length of a twisted pair segment max. 100 m (328 ft)
F/O port
According to IEEE 802.3u 100BASE-FX
System attenuation
50/125 µm fiber 8 dB
62,5/125 µm fiber 11 dB
Wave length 1300 nm
F/O line length (example)
50/125 µm fiber 3000 m (9843 ft) maximum (data on fiber: 1.6 dB/km, 500 Mhz*km)
62,5/125 µm fiber 3000 m (9843 ft) maximum (data on fiber: 2.6 dB/km, 500 Mhz*km)
Scope of delivery
Ethernet Transceiver 100 Mbps TX/FX incl.
terminal block for supply voltage
Quick reference guide
Order number
Ethernet transceiver 100 Mbps TX/FX 499NTR00100
Accessories
Ethernet SFTP cat5RJ45 cords 490NTW000 ii
Ethernet SFTP cat5RJ45 crossed cords 490NTC000 ii
Ethernet MTRJ/SC 5 m optical patch 490NOC00005
Ethernet MTRJ/ST 5 m optical patch 490NOT00005
Note: The optical patch is made up of two 62.5/12.5 multi mode glass fiber, used in 1300 nano-meter wavelengths.
Ethernet reference Manual 490USE13300
