Supplied Hardware
This list identifies the hardware you will use to assemble the product . To help distinguish between the various types of the screw
and bolts, use the scale below to measure them and compare them to the size listed .
No. Description Qty.
802 M4×15 Screw 27
805 M8×45 Bolt 2
810 M8×18 Bolt 8
811 M8×52 Bolt 2
812 φ8 Washer 12
845 M8×75 Bolt 2
A
Screw driver
1
B Allen key 1
C Allen Wrench 1
D Safety Key 1
E Power Cord 2
845
810 811 805
812
802
A B
C
D E
MILLIMETERS
