T.60 TURNTABLE CONTENTS
1) Start/Stop
Button
2) Strobe Dots
3) Slip Mat
4) Center Spindle
5) Power Switch
6) 33/45 Button
7) Target Light Base
8) Pitch Control Slider
9) Headshell Locking Nut
10) Tonearm
11) Arm
Rest
12) Counterweight
13) 45-rpm
Adaptor
14) Position For Preparing Cartridge
15) Phono
Output
16) GND
17) Power Cord Connector
PLACEMENT
• Do not place the unit in a location where it will be exposed to direct sunlight or near a heating appliance.
• Do not place the unit in a location where there is high humidity or a lot of dust.
• Cartridge may pick up slight sound pressures or vibrations from the speakers coming along the floor or through the air
resulting in feedback. Find a location which is very stable and vibration free.
• The legs have functions for adjusting the height of the unit itself. Adjust the legs to stabilize the main body horizontally.
ASSEMBLY
1. Remove the main unit with the packing from the box
and take off the packing.
2. Insert the turntable platter onto the center spindle.
3. Set the slip mat on the platter.
4. Installation of cartridge:
When installing a cartridge, refer to the operating
instructions of that cartridge.
During installation, attach the stylus protector to
guard the stylus tip from damage.
(1) Connect the lead wires to the cartridge terminals.
The terminals of most cartridges are color
coded.
Connect each lead wire to the terminal of the
same color.
White (L+)
Left channel+
Blue (L-) Left channel-
Red (R+) Right channel+
Green (R-) Right channel-
(2) Install the cartridge to the headshell and tighten
it with screws provided with the cartridge.
5. Insert the headshell into the front end of the tonearm,
then turn the lock nut clockwise with the headshell
firmly held horizontally.
6. Slide counterweight onto tonearm. Twist it lightly
and it will screw onto the rear shaft of the tonearm.
7. Adjustment of horizontal zero (0) balance and stylus
pressure:
(a) Remove the stylus protector, do not touch the
stylus tip during the adjustment.
(b) Release the arm clamp and lift the tonearm from
the arm rest to free it.
(c) Rotate the counterweight until the tonearm is
approximately balanced horizontally (floats
freely).
(d) Refasten the tonearm with the arm clamp.
(e) Hold the counterweight stationary with one hand
and rotate only the stylus-pressure ring to bring
the number "0" of the ring into alignment with
the center line on the tonearm rear shaft.
(f) Rotate the counterweight clockwise until the
scale shows the value corresponding to the
pressure of the used stylus. The average stylus
pressure of the cartridge body is 1.5-2 g. If you
use a non-Stanton cartridge, please follow that
manufacturer’s instructions.
8. Install the cloth dust cover to the main unit.
