SEZ S ERIES C OUNTERTOP S TEAMERS
T ROUBLESHOOTING
O PERATOR ’ S M ANUAL 1181587 P AGE 35
TROU
BLE
S
H
OOTI
N
G
Figure 18
High-Limit Thermostats Check
1. Note: Allow cavity bottom to cool before performing this test.
2. Disconnect left thermostat lead wire from NO position of R1 relay.
3. Disconnect right thermostat lead wire from wire B58.
4. Disconnect remaining thermostat lead wires from each other.
5. Test each thermostat for continuity. Replace as necessary.
6. Reconnect all thermostat lead wires.
