PART IDENTIFICATION CHART

Use the chart below to identify the small parts used in
assembly. The number in parenthesis below each part
refers to the key number of the part, from the PART
LIST on page 14. The number after the dash indicates

the quantity needed for assembly. Note: Some parts
may have been pre-attached for shipping. If a part
is not in the parts bag, check to see if it has been
pre-attached.

M8 x 19mm

Button Screw (10)–2

M8 x 63mm Carriage Bolt (49)–4

M5 x 30mm

Button Bolt (51)–4

M8 x 38mm Button Bolt (53)–2

M4 x 12mm

Button Screw (57)–4

M5 Nylon

Locknut (52)–4

M8 Nylon

Locknut (50)–8

1/2” Nylon

Locknut (35)–2

M8 x 60mm Bolt (56)–2

Pivot Washer (54)–2

Pedal Washer (32)–2

M4 x 19mm Flange

Screw (55)–6

Note: Extra parts may be included.
