HD45 PARTS LIST
Item
No.
Part No.
Qty
Description
1
04369
1
Handle
2
04371
1
Trigger
3
04077
1
Valve Spool, OC
04593
1
Valve Spool, CC
4
01650
1
Charging Valve
5
00844
2
Spirol Pin, 1/4 x 1/2
6
04372
2
Capscrew
7
04932
2
Side Rod
8
04374
2
Lock Nut
9
04056
1
Rod Wiper
10
01362
1
O-Ring
11
00293
1
O-Ring
12
04057
1
Bushing
13
04058
1
Spring
14
07479
1
Accumulator Diaphragm
15
05988
1
Accumulator, Valve Block Assy.
16
04378
1
Porting Block
17
04379
2
O-Ring
18
04380
1
Automatic Valve Body
19
02900
4
Roll Pin, 1/8 x 1/2
20
04381
2
Back-Up Ring
21
04571
2
Push Pin
22
04382
1
Automatic Valve
23
04383
1
Flow Sleeve Tube
24
04605
4
Push Pin
25
04384
1
Flow Sleeve
26
04954
1
Piston
27
02022
1
O-Ring
28
04386
1
Cup Seal
29
04780
1
Washer
30
04934
1
Cup Seal
31
05243
1
Orifi ce Plug
32
03786
1
GPM Decal
33
28376
1
Stanley Decal
34
00682
2
Capscrew
35
07493
1
Charge Valve Cap
36
11197
2
Back-Up Ring
37
02494
2
Handle Grip
38
01652
2
Hose Assy.
39
04936
2
Capscrew
40
25534
2
Washer
41
04937
1
Motor Control Valve
42
01211
1
O-Ring
43
04938
1
Washer
Item
No.
Part No.
Qty
Description
44
01607
1
Set Screw
45
04939
1
Lever
46
04940
1
Retaining Ring
47
00783
3
Pipe Plug
48
03826
2
Bearing
49
04033
1
Idler Gear
50
00713
2
Dowel Pin
51
04942
1
Motor Plate
52
01257
1
O-Ring
53
11196
2
Quad Ring
54
04944
1
Drive Hex (Land Model)
06678
1
Drive Hex (U/W Model)
55
04787
1
Key
56
05976
1
Motor Chamber
57
05975
1
Drive Gear
58
04947
2
Bearing
59
04948
1
Thrust Washer
60
04949
1
Thrust Back-Up Washer
61
04950
1
Gasket
62
04759
1
Spring Back-Up
63
04951
1
Drive Motor Control Block (Land
Model)
05680
1
Drive Motor Control Block (U/W
Model)
64
16445
1
Latch
65
07063
8
Wave Spring
66
04756
2
Latch Washer
67
04761
1
Retaining Ring
68
01749
2
Roll Pin
69
00114
1
Roll Pin
70
00018
2
O-Ring
71
29689
1
Name Tag (CE Only)
72
66297
1
Sound Power Decal (CE Only)
73
11207
1
Circuit Type D Decal (CE Only)
74
28322
1
CE Decal (CE Only)
75
28409
1
Composite Decal (CE Only)
76
01605
2
O-Ring
77
07594
1
Trigger Lock
78
07593
1
Spring
79
00224
1
Retainer Ring
80
24058
1
Coupler, Female
81
24059
1
Couper, Male
05839
1
SEAL KIT
