802.11 (Wireless Models Only)
! Variable data rates up to 54 Mbps
! Frequency band: 2.4/5 GHz (5GHz on SX-200 only)
! WPA and WPA2 (personal and enterprise modes)
! 802.1x EAP with TTLS/LEAP/PEAP
! Wired equivalent privacy: 128-bit, 64-bit (compatible
with 40-bit), none
! Range: 100 m
! Reverse PIN SMA L-type swivel dipole dual band
antenna
Network Ports:
!
Supports standard Ethernet/Fast Ethernet connections:
twisted-pair
!
RJ45 (10/100Base-T)
!
802.11a/b/g (SX-200 wireless) or 802.11b/g (SX-215 wireless)
Protocols:
TCP/IP and Windows
! Supports lpr/lpd network printing protocol
! Supports raw printer port (for example, Port 9100)
! Supports NetBIOS over IP and NetBEUI
! Supports telnet and ftp
! Supports SNMP MIB I & II
! Supports IPP protocol (Internet printing)
! Supports peer-to-peer printing (direct printing) via the
Microsoft DLC,
! TCP/IP or IPX/SPX protocols with ExtendNet Connect
EtherTalk Mode:
!
Supports Macintosh System 6.X, 7.X, 8.X, 9.X, MacOS 10.X
!
Supports EtherTalk Phase 2
!
Supports Apple LaserWriter driver 8.X and above
(PostScript printer required)
!
Supports PostScript-compatible laser printers
!
Supports most HP, Epson, and Canon inkjet printers
NetWare Mode:
! Simultaneously supports Novell NetWare, NDS & NDPS
! Supports NDPS via Novellís Generic Gateway or HPís
Printer Gateway
! Supports packet signatures, checksums and aliasing
! Supports dedicated print server and remote printer modes
! Supports encrypted passwords
! Supports up to eight le servers and up to 32 queues
! Supports automatic le server reattachment
Print Server Management Tools:
Enterprise Management Tools
! Supports PC-based SNMP applications (For example, HP
OpenView, IBM NetView and Sun SunNet Manager)
!
Supports Private MIB
LAN Administration Tools
!
ExtendView Utilities – Silex utilities which provide simple
conguration and management capabilities.
- ExtendView also displays system, network and printer
status information via SNMP traps
!
NetworkAlert Utilities – Silex utilities that assist in
managing network printers by proactively alerting you of
printer problems via SNMP traps. Integrates into ExtendView
for advanced diagnostic and conguration information.
!
XAdmin32, XAdmin – Compatibility with legacy silex Print
Server Administration utilities.
!
WebXAdmin – Web Browser allows print server conguration
and management HP JetAdmin and HP.
! Web JetAdmin – allows print server conguration and
management Novell ManageWise.
User Printing Status and Monitoring
! HP JetAdmin and Web JetAdmin for printer and print server
status information
! WebXAdmin for printer and print server status information
Other Features:
! LEDs to indicate power-on, link, activity
! lpd-Plus virtual printer capability (allows complex user-
dened setup and reset strings congurable on a per-
service basis)
!
Text-to-PostScript conversion on a per-service basis
!
Programmable character string conversion
!
IP security (ability to restrict access to print server
based on IP address)
!
Congurable TCP port numbers on a per-service basis
!
IP address conguration via arp, rarp, DHCP, BOOTP,
silex ExtendView, HP JetAdmin/Web JetAdmin,
NetWare, and DEC MOP
! Automatic detection of NetWare frame type or frame
type can be forced AppleTalk ìspoongî for support of
non-bidirectional PostScript printers
! AppleTalk binary printing (requires that printer supports
the HP Tagged Binary Communications Protocol or can
be forced into binary mode)
! Online HELP
! Sophisticated diagnostics, including protocol trace
capability
Networking Example:
USB printer
Ethernet LAN backbone
SX-200
802.11a/b/g Wireless
Access Point
SX-200
Wireless
USB printer
Parallel printer
Parallel printer
