DESCRIPTION OF
PAR
TS
DRAIN-HOSE (PUMP)
WATER SUPPLY HOSE(HOT)
WATER SUPPLY HOSE (COLD)
LID
Be sure to keep the lid
closed during washing
and spinning.
Lint will be collected in
the filter during
washing.
FILTER
DETERGENT BOX
The User
’s Manual is for common use.
Make use of the User
’s Manual depending upon your washing machine model.
GROUND LEAD
When the water pipe is
metal, make sure to cover
the end of the ground wire.
POWER CORD
WATER DRAIN HOSE
SOUND ABSORPTION
PANEL
SPIN BASKET
ADJUSTABLE LEGS
Adjust the length
of the legs when
installing the washer.
FRONT CONTROL
PANEL
BLEACH INLET
FABRIC SOFTENER
DISPENSER
PULSATOR
