HX600S Page 49
15. SPECIFICATIONS
Performance specifications are nominal, unless otherwise indicated, and are
subject to change without notice.
15.1 GENERAL
Frequency Ranges (MHz): 156 MHz - 163.275 MHz (Marine Band + WX Band)
Channel Steps: 25 kHz
88 MHz - 108 MHz (FM Broadcast Receive only)
Channel Steps: 100 kHz
500 kHz - 1800 kHz (AM Broadcast Receive only)
Channel Steps: 10 / 9 kHz
108 MHz - 137 MHz (AIR Band)
Channel Steps: 25 kHz
Frequency Stability: ±10 ppm
(–4 °F to +140 °F [–20 °C to +60 °C])
Emission Type: 16K0G3E, 16K0G2B
Antenna Impedance: 50 Ohms
Supply Voltage: Nominal: 7.2 V DC, Negative Ground
(Battery Terminal)
Current Consumption: 170 mA (Receive)
50 mA (Standby)
1.45 A (5 W Power transmit)
1.0 A (2.5 W Power transmit)
0.6 A (1 W Power transmit)
Operating Temperature: –4 °F to +140 °F (–20 °C to +60 °C)
Case Size (W x H x D): 2.36” x 4.09” x 1.2” (60 x 104 x 30.5 mm)
w/o knob & antenna
Weight (Approx.): 13 oz. (370 g) with FNB-83, Antenna
15.2 TRANSMITTER
RF Power Output (@7.4 V): 5, 2.5 or 1 W
Modulation Type: Variable Reactance
Maximum Deviation: ±5 kHz
Spurious Emission: At least 65 dB below
Microphone Impedance: 2 k-Ohm
