Sennheiser EK 300 IEM - Manual (Page 12)

11
Using the operating menu
Using the operating menu
A special feature of the Sennheiser ew G3 series is the consistent, intuitive
menu structure of transmitters and receivers. As a result, adjustments to
the settings can be made quickly – even in stressful situations, for example
on stage or during a live show or presentation.
The buttons
Overview of the operating menu
Button Function of the button
Press the ESC button • Selects a standard display (see page 10)
• Cancels the entry and returns to the current
standard display (ESC function)
Press the SET button • Changes from the current standard display
to the operating menu
• Calls up a menu item
• Enters a submenu
• Stores the settings and returns to the
operating menu
Press the rocker button • In Focus mode:
Adjusts the balance (see page 16)
• In stereo mode:
Selects a standard display (see page 10)
• Changes to the next/previous menu item
• Changes the setting of a menu item
Display Function of the menu item Page
Main menu “Menu” 14
Squelch Adjusts the squelch threshold 14
Easy Setup Scans for unused frequency presets, releases
and selects frequency presets
15
Frequency Preset Sets the frequency bank and the channel 15
Name Enters a freely selectable name 15
Balance Adjusts the balance 14
Mode Selects stereo or Focus mode 14
High Boost Activates/deactivates the treble boost 16
Auto Lock Activates/deactivates the automatic lock mode 16
Advanced Calls up the extended menu “ Advanced Menu ” 17
Exit Exits the operating menu and returns to the
current standard display
–
ESC
SET
Main menu
“Menu”
Squelch
Easy Setup
Frequency Preset
Name
Balance
Mode
High Boost
Auto Lock
Advanced
Exit
Tune
Pilot Tone
Limiter
LCD Contrast
Reset
Software Revision
Exit
Extended menu
“Advanced Menu”
Reset List
Current List
Scan New List
“Easy Setup”
