Scotsman Ice NME954 User Manual
Page 11
BK
BK
EARTH GROUND
BU
JUNCTION BOX
USE COPPER CONDUCTORS ONLY
THIS UNIT MUST BE GROUNDED
ALL CONTROLS SHOWN IN
ICE MAKING MODE
CONTROL BOX
CIRCUIT BOARD
SEE NAMEPLATE
FOR SUPPLY VOLTAGE
AND MAX FUSE SIZE
BK
7-2678-01
(AIR COOLED
ONLY)
V
BU
BK
BU
BU
4
1
S-A1
2
AUGERDRIVE
MOTOR
OL
RUN
START
NC
CENTRIFUGAL
SWITCH
R
MODE SWITCH
BU
COMPRESSOR
Y
Y
L2
L1
T2
T1
RUN
CAP
1
2
5
POTENTIAL
RELAY
START
CAP
HIGHPRESS
CONTROL
BK
R
Y
COND
FAN
3
6 5
2 1
4
V
BK
BK
GN
C
R
S
R
R
BU
BU
CONTACTOR
CONDUCTIVITY
PROBE
BK
R
BK
BK
R
7
8
9
4
5
6
1
2
3
BIN FULL
EMITTER
(LED)
BIN FULL
DETECTOR
PHOTOTRANS
LOWPRESS
CONTROL
AIR AND WATER COOLED, 208-230/60/1
NME954 & FME1204 SERVICE PARTS
January 2000
Page 11
