Model No.
Image sensor
Number of pixels
Minimum illumination (approx.)
Video S/N ratio
Lens mount
Flange back
Backlight compensation
White balance
AGC
Electronic shutter
Electronic iris
Auto iris control
Gamma
Aperture compensation
Day/Night
DNR
Title
Motion detection
Face detection
Privacy mask
VCC-HD2500 VCC-HD2300 VCC-HD2100
Technical Specifications
Camera
Network
Full HD CS-Mount Camera Series
Interface
General
1/3" Progressive Scan CMOS
Effective 16:9 1920 (H) x 1080 (V) 4:3 2288(H) x 1712(V)
More than 50 dB (AGC off)
CS mount
12.5mm ±0.5mm electronic adjustment with focus assist drive
ATW/AWC/MWB/Outdoor/Indoor/Fluorescent
Adjustable R and B signals in MWB mode
Normal/Middle/High/Off Adjustable, gain control in Off mode
1/30 1/60 1/100 1/250 1/500 1/1000 1/2000 1/4000 1/10000
Long shutter : x1 x2 x4 x8 x16 x32
Yes
DC type
0.45/1/Mode1/Mode2
On/Off
3D
16 Characters
On/Off
Yes, Video analytics
Yes
4
Yes
No
2
MJPEG / H.264
Quality: (BASIC, NORMAL, ENHANCED, FINE, SUPER FINE) Bitrate: Chageable
Max. 30 ips (1920x1080)
Multi stream H.264 and MJPEG (Max.1920x1080 30 ips)
TCP/IP, UDP, HTTP, HTTPS, SMTP, NTP, DHCP, FTP, DDNS, RTP, RTSP
Max. 20
BASIC authentication (ID/password), SSL supported (Only JPEG), IP filtering
<16:9> 1920x1080 / 1280x720 / 640x360 / 320x180
<4:3> 1600x1200 / 1280x960 / 1024 768 / 640x480 / 320x240
<16:9> 1920x1080 / 1280x720 / 1024x576 / 640x360
<4:3> 2288x1712 / 1600x1200 / 1280x960 / 1024x768 / 800x600 / 640x480 / 320x240
Composite out (for adjustment only)
10BASE-T/100BASE-TX (RJ45 connector)
2/2
Temperature: -10 to +50°C (14°F to 122°F) Humidity: within 90% RH
Temperature: -20 to +70°C (-4°F to 158°F) Humidity: within 70% RH
24V AC ±10%, 60 Hz/ 12 - 15 V DC, PoE (IEEE802.3af)
72.4 x 44.8 x 75.2 mm (2.85 x 1.76 x 2.96 inch)
Monitor output
SD memory card slot
Network port
Alarm input/output
Audio input/output
Environmental conditions
Power supply
Power consumption (approx.)
Dimensions (approx.) (W x H x D)
Weight (approx.)
*Specifications, design and availability are subject to change without notice.
Image compression
Resolution
Picture quality
Frame rate
Streaming number
Video streaming
Audio compression method
Protocol
Simultaneous access capacity
Security
Operating
Storage
True Day/Night
G.711, Bidirectional (Full duplex)
1(SDHC)
Mic in/Line out (3.5 Φ mini jack)
6.8w
250g (8.82 oz)
4.6w
220g (7.76 oz)
Color 1.0 lux(F1.2, GAIN HIGH), B/W 0.1 lux (F1.2, GAIN HIGH) Color 1.0 lux (F1.2, GAIN HIGH)
Multi/Center/Face/Off, Mask settings possible Multi/Center/Off, Mask settings possible
H.264
MJPEG
Dimensions
Unit: mm (inch)
44.8
1.76”
72.4 2.85”
19.5 0.77”
28.6
1.13”
LENS
85 3.35”
75.2 2.96”
11.2 0.44”
Distributed by:
Digital System Company of SANYO Electric Co., Ltd. obtained
Quality Management System ISO9001 and Environmental
Management System ISO14001 certifications.
Digital System Company
http://www.sanyosecurity.com
Caution: Please consult the instruction manual to ensure safe and proper operation of the product.
SANYO Electric Co., Ltd.
SMS178
©2009 SANYO Printed in Japan 2009.10.NP
