Hooking Up the Turntable
The phono cable comes attached to the rear of
the cabinet.
1
Set the PHONO/LINE switch (on
the rear of the turntable) according
to the jacks of your stereo system
(amplifier).
• When your stereo system (amplifier) has
PHONO input jacks (connect to PHONO
input jacks)
set to PHONO. The Equalizer function
is off.
• When your stereo system (amplifier) does
not have PHONO input jacks (connect to
AUX, VIDEO input jacks, etc.)
set to LINE. The Equalizer function
is on.
2
Connect the cable with the white
plug to the white (L) jack and connect
the cable with the red plug to the red
(R) jack.
Make sure to insert the plugs firmly into the
jacks. If the plugs are not inserted firmly,
noise may occur.
3
Connect the AC power cord.
Connect the AC power cord to an AC
wall outlet after completing all of the
connections by performing steps 1 and 2.
 to a wall outlet
