Control elements
Signal from LED display
º
:
³
Headband
· Normal
/
bypass
sliding switch
»
Connection for audio cable
¿
Audio cable
´ ON/OFF
button
²
VOLUME –
button
¶ TalkThrough
button
º
LED (red/green)
¾
VOLUME +
button
µ
Ear cushions
¸
Battery compartment
LED
Meaning
red
NoiseGard 2.0 is switched on (see page 11)
green
TalkThrough is switch on (see page 12)
flashing
Batteries or rechargeable batteries almost empty (see page 7)
³
µ
·
¸
´
²
¶
º
¾
¿
»
