Sanyo PLC-XE40 - Manual

Education Projectors From
The Number One Brand!
Sanyo Oceania Pty Ltd PO Box 947 North Ryde BC NSW 1670 AUSTRALIA
THE SANYO RANGE OF
EDUCATION PROJECTORS
For more information call 1300 360 230 or visit www.sanyo.com.au
Piccadilly Circus, London, since 1980
EDUCATION PROJECTORS
MODEL NAME PLC-XE32 PLC-XE40 PLC-XE50
Panel 0.6 inch TFT p-Si x 3 0.6 inch TFT p-Si x 3 0.8 inch TFT p-Si x 3
No. of pixels 2,359,296 (1024 x 768 dots) 2,359,296 (1024 x 768 dots) 2,359,296 (1024 x 768 dots)
Projection lamp 200W UHP Lamp 200W Lamp 275W Lamp
Brightness 1500 ANSI lumens 1500 ANSI lumens 2000 ANSI lumens
Uniformity 85% (corner to centre) 80% (corner to centre) 80% (corner to centre)
Contrast ratio 400:1 400:1 600:1
Keystone correction Digital Keystone ± 20° vertical Digital Keystone : ± 20° vertical Digital Keystone : ± 5° vertical
Throw ratio 1.75 – 2.1:1 78" Image @ 1m 80" Image @ 9cm
Throw distance 1.4m - 13.2m 0.77m -1.04m -4cm - 9cm
IWB Screen size
Compatibilty 60" - 80" 60" - 80" 60" - 80"
Inputs Input 1: Dsub15 Input 1: 1 x Dsub15 Input 1: 1 x Dsub15
Input 2: 1 x RCA for Composite Video Input 2: 1 x Dsub15 (Switchable) Input 2: 1 x Dsub15 (Switchable)
Input 3: Dsub15 Monitor out Input 3: 1 x RCA Input 3: 3 x RCA (Component)
Input 4: Audio Out Input 4: Audio Out Input 4: Audio Out
Colour systems PAL/ SECAM/ NTSC/ NTSC4.43 PAL/ SECAM/ NTSC/ NTSC4.43 PAL/ SECAM/ NTSC/ NTSC4.43
/ PAL-M/N / PAL-M/N /PAL-M/N
Computer compatibility SXGA/ XGA/ SVGA/ VGA/ MAC UXGA/ SXGA/ WXGA/ SVGA/ VGA UXGA/ SXGA/ WXGA/ SVGA/ VGA
Service Port RS232 Control (Mini DIN 8 Pin) RS232 Control (Mini DIN 8 Pin) RS232 Control (Mini DIN 8 Pin)
Sound output 1.0W mono 1.0W mono 2.0W mono
Voltage 100V-240V AC (auto voltage) 100V-240V AC (auto voltage) 100V-240V AC (auto voltage)
Dimensions(W x H x D) 330 x 80 x 237 mm 320 x 148 x 292 mm 374 x 196.8 x 495 mm
Weight 2.9kg 3.3kg 7.2kg
