7
It is important that the cells be firmly anchored and aligned before
the flume is attached to the 2nd cell.
7. Repeat steps 2 and 3 for 2nd top section on AV63000 thru AV67000
models.
8. Repeat steps 4 through 7 for any remaining cells.
9. Attach your cold water supply piping to the cold water basin outlet
connection in accordance with drawing instructions, and utilizing
gaskets provided by Marley.
Do not support your pipe from the tower or outlet connection—support
it externally.
Normally, one of the following three outlet arrangements is provid-
ed:
Cased face or air inlet face suction connection: This is a factory-
installed, galvanized pipe nipple, extending horizontally from the side,
or end of the cold water basin. It is both beveled for welding—and
grooved for a mechanical coupling. If a weld connection is used, it
is recommended that the weld area be protected against corrosion.
Cold galvanizing is suggested, applied according to the manufacturer’s
instructions.
Bottom outlet connection: This is a factory-installed, screened cir-
cular opening in the cold water basin floor of one or more cells. An
appropriately-sized circular opening has been drilled to accept a 125#
ANSI B16.1 flat-face flange connection.
10. Attach makeup water supply piping to the float valve connection
located at the air inlet face of the tower. If you wish to pipe overflow
and drain water to a remote discharge point, make those connections
at this time.
11. Attach your warm water return piping to the inlet connections of the
tower.
Do not support your pipe from the tower or inlet connection—support
it externally.
➠
Caution
Installation
Note
Caution
