EmETX-i602 Quick Installation
Flat Panel VGA
LCD1
Type : Onboard 40-pin Box Header (Hirose DF-40DS-1.25C)
Pin
Description
Pin
Description
1
VCC5V
2
VCC5V
3
GND
4
GND
5
VCC3V
6
VCC3V
7
NC
8
GND
9
FPD0
10
FPD1
11
FPD2
12
FPD3
13
FPD4
14
FPD5
15
FPD6
16
FPD7
17
FPD8
18
FPD9
19
FPD10
20
FPD11
21
FPD12
22
FPD13
23
FPD14
24
FPD15
25
FPD16
26
FPD17
27
FPD18
28
FPD19
29
FPD20
30
FPD21
31
FPD22
32
FPD23
33
GND
34
GND
35
SHFCLK
36
HSYNC
37
M(DE)
38
VSYNC
39
ENABLK
40
ENAVEE
LCD2
Type : Onboard 20-pin Box Header (Hirose DF-20DS-1.25C)
Pin
Description
Pin
Description
1
GND
2
GND
3
FPD24
4
FPD25
5
FPD26
6
FPD27
7
FPD28
8
FPD29
9
FPD30
10
FPD31
11
FPD32
12
FPD33
13
FPD34
14
FPD35
15
GND
16
GND
17
NC
18
NC
19
NC
20
NC
