EmETX-i602 Quick Installation
Jumper/Connector Quick Reference
Connectors
Lable
Function
Page
LCD1
LCD TTL Connector 1
9
LCD2
LCD TTL Connector 2
9
ETX1
PCI Bus, USB, Audio
10
ETX2
ISA Bus
10
ETX3
VGA,LCD,Video,COM1,COM2,LPT,IrDA,M/K
11
ETX4
IDE1,IDE2,Ethernet,Miscellaneous
11
