Keyboard button Use to:
RIGHT ARROW Move to the right in the scene.
DOWN ARROW Move backward in the scene.
PAGE DOWN Lower elevation.
ESC Close
N
N O T E
As you navigate the 3D scene, a red indicator in the map displays where you are in the scene
and the direction you are viewing.
Upward Downward Off-screen (decline)
Incline Decline Level
4. Press Close when you’re done.
Disguising 3D models before presenting them
If you want to hide 3D models in your .notebook file before presenting them, you can use the Disguise
feature to hide the 3D models with a magic hat.
N
N O T E
If you hide multiple 3D models on the same page with magic hats, each magic hat has a different
colored ribbon.
g To hide a 3D model with a magic hat
1. Select the 3D model.
2. Press the 3D model’s menu arrow, and then select Disguise > Disguised.
C H A P T E R 2
Inserting and manipulating 3D models
12
