Display Modes
If the signal from the system equals to the standard signal mode, the screen is adjusted auto-
matically. If the signal from the system doesn't equal to the standard signal mode, adjust the
mode with referring to the Videocard user guide because the screen might not display or only
the power LED might be on. For the display modes listed below, the screen image has been
optimized during manufacture.
1600 x 1200 / 1920 x 1200 Mode change function
The recommended mode of SyncMaster 240T is 1920 x 1200,
however you may prefer 1600 x 1200 to 1920 x 1200.
Then, please use mode change function for optimal screen display.
1. Press "menu" button on the Monitor front.
2. Choose "information" menu by using +/- key
3. Press "menu" button 7 times continuously
4. Then, the mode change funcion operates
5. If you want to revert to the original mode, then do the 1-3 procedure again.
Table 7. Preset timing modes
Mode Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
Frequency
(MHz)
Sync
Polarity
(H/V)
VGA
720 x 400 31.469 70.087 28.322 –/+
640 x 480 31.469 59.940 25.175 –/–
640 x 480 37.500 75.000 31.500 –/–
640 x 480 43.269 85.008 36.000 –/–
SVGA
800 x 600 46.875 75.000 49.500 +/+
800 x 600 53.674 85.061 56.250 +/+
XGA
1024 x 768 48.363 60.004 65.000 –/–
1024 x 768 60.023 75.029 78.750 +/+
1024 x 768 68.677 84.997 94.500 +/+
SXGA
1280 x 1024 63.981 60.020 108.000 +/–,+/–
1280 x 1024 79.976 75.025 135.000 +/+
UXGA (Analog only) 1600 x 1200 75.000 60.000 162.000 +/–,+/–
WUXGA
(Analog/240T only)
1920 x 1200 75.000 60.000 193.156 +/–,+/–
Appendix
