Shark EP708 - Manual (Page 4)

OPERATING INSTRUCTIONS cont. OPERATING INSTRUCTIONS cont.
• Rinse the post motor filter in
lukewarm water and dry the filter
completely. (fig. J) Do not use a
washing machine to rinse the filter.
Do not use a hair dryer to dry it. Air
dry only. Never operate the vacuum
without the post motor filter in place.
• When the filter is dry, replace into
the unit and replace the filter cover
over it.
• A severely solid or clogged filter
should be thoroughly washed
with fresh tepid water. A mild
detergent can be used if required.
7. Changing & Cleaning the Pre-
Motor Filter
The pre-motor filter is a washable filter
but should be replaced every three (3)
to six (6) months depending on usage.
• Remove the pre-motor filter from the
dust cover. (fig. G)
• Rinse the pre-motor filter in
lukewarm water and dry the filter
completely. (fig. H) Do not use a
washing machine to rinse the filter.
Do not use a hair dryer to dry it. Air
dry only. Never operate the vacuum
without the pre-motor filter in place.
• When the filter is dry, replace into
the unit and replace the filter cover
over it.
• A severely solid or clogged filter
should be thoroughly washed
with fresh tepid water. A mild
detergent can be used if required.
Fig. G
Fig. H
Fig. I
Fig. J
9. Cleaning the Dust Cup
The dust cup can be washed in
lukewarm water. Do not use strong
detergents. Ensure that dust cup is
fully dry before putting back on the
machine. (fig. K) Do not wash in
dishwasher.
Fig. K
11. Operation
The upright vacuum can be used on
multiple types of carpeting, bare floors or
upholstery with attachments. When using
the attachment tools such as the crevice
nozzle or the dusting brush, place the
handle in the upright position.(fig. N)
• Plug power cord into electrical
outlet.
• Step on the handle release button
to release the handle.
• Press the On/Off switch to the On
position.
• You are now ready to vacuum.
10. Using the Blower Attachment
The vacuum comes with a blower
attachment. To use this attachment,
remove the post motor filter cover and
replace with the blower attachment. (fig. L)
Take the hose part that has the tabs on
it and insert into the "J" slot and turn
until it locks. (fig. M)
You can use the hose alone or with an
extension tube to reach very tight places
such as under beds, sofas or furniture.
Fig. L
Fig. M
Fig. N
Fig. O
Fig. P
Occasionally the power nozzle drive belt
will require changing, the frequency will
depend upon the amount of use your
vacuum sees.
• Turn unit “Off” and unplug from
wall outlet.
• Use a Phillips screwdriver and
remove the four (4) screws from the
top of the motorized power head
cover. (fig. O)
• Remove the cover of the motorized
power head.
• If the belt has broken, remove any
loose pieces before replacing.
• Lift the agitator up as is in fig. P
below.
• Remove the belt by turning it
sideways around the motor shaft
and pull out. (fig. Q)
Fig. Q
12. Cleaning & Changing the Belt
Warning
: Always disconnect from
power source when servicing or
cleaning the unit. Failure to do so could
result in electrical shock or personal
injury from cleaner suddenly starting.
8. Changing & Cleaning the Post
Motor Filter
The post motor filter is a washable
filter but should be replaced every
three (3) to six (6) months depending
on usage.
• Remove the filter cover from the
rear of the unit. (fig. I)
6 7
