System connections
Front speaker (left)
Front speaker (right)
Subwoofer
AC outlet
(AC 120 V, 60 Hz)
Speaker connection (see page 11)
AM loop antenna
FM antenna
Make sure to unplug the AC power cord before any connections.
FM/AM loop antenna connection (see page 11)
Connecting the AC power cord (see page 12)
