51
R
Section 8
SHEET METAL COMPONENTS
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
451481
04001-09
483371
482621
491729
424819
04001-117
04019-05
*
48903
421274
04003-12
423308
04029-01
04019-03
04003-01
48661
43584
04003-04
482622
04021-09
462329
04019-04
04017-27
451480
423489
04021-09
04001-19
04001-125
04021-13
481559
04021-20
481657
482028-01
45
2196
45 2197
45 2198
45 2199
45 2200
45 2201
481025
04021-07
45934
451416
04001-134
04001-167
43581
43583
9277
9278
04001-01
04001-01
423674
481284
Fender Weldment, RH
Bolt, Hex Head, 5/16-18 x 1, Zinc
Spring, Seat Latch
Bearing w/ Race
Seat Plate w/Decal
Guard, Fuel Line
Bolt, Hex Head 7/16-14 x 1-3/4”
Nut, 7/16-14 Serrated Flange
Battery (not avail. through Scag)
Pad, Battery Cover
Cover, Battery
Bolt, Carriage 5/16-18 x 3/4”
Plate, Battery Box
Wing Nut, 1/4-20 x 3/4”
Nut, Hex Serrated Flange 5/16-18
Bolt, Carriage 1/4-20 x 6”
Rubber Pad
Spacer, Caster Wheel
Bolt, Carriage 5/16-18 x 1”
Seal
Locknut, 3/8-16, Elast. Stop
Main Frame w/Decals
Nut, Hex Serrated Flange 3/8-16
Screw, Hex Serrated Flange 3/8-16 x 1”
Fender Weldment, LH
Foot Plate
Nut, Hex Elastic Stop 3/8-16
Bolt, Hex Head 3/8-16 x 1”
Bolt, Hex Head 5/8-11 x 4”
Nut, Hex Elastic Stop 5/8-11
Cap, Grease
Nut, Hex Elastic Stop 1.0-14
Bearing W/Race
Plug, 1/4-28 THD Form
Extention Weldment, Caster 52V (LH)
Extention Weldment, Caster 52V (RH)
Extention Weldment, Caster 61V (LH)
Extention Weldment, Caster 61V (RH)
Extention Weldment, Caster 72VS (LH)
Extention Weldment, Caster 72VS (RH)
Seal, 2.00” OD. x 1.625” Bore
Nut, Hex Elastic Stop 1/2-13
Yoke Weldment, Caster (52V)
Yoke Weldment, Caster (61V & 72A/VS)
Bolt, Hex Head 1/2-13 x 7-1/2” (52V)
Bolt, Hex Head 1/2-13 x 9-1/2” (61V &
72A/VS)
Sleeve, Caster Wheel (52V)
Sleeve, Caster Wheel (61V, 72A/VS)
Wheel Assy, 52V (Incl. items 20, 54, 55)
Wheel Assy, 61V, 72A (Incl. 20, 54, 55)
Bolt, Hex Head 1/4-20 x 3/4”
Bolt, Hex Head 1/4-20 x 3/4”
Mounting Bracket, STT Cup Holder
Bumper, Rubber 46
47
48
49
50
51
04050-01
484341
9240
491731
46
2312
46 2313
46 2314
46 2315
46 2316
46 2317
48114-10
Retaining Ring, .625” Ext. “E”
Grip, Seat Latch
Cup Holder Assembly
Lever Assembly, Seat Release
Caster Wheel Assembly (Incl. 31 thru 43)
52V (LH)
Caster Wheel Assembly (Incl. 31 thru 43)
52V (RH)
Caster Wheel Assembly (Incl. 31 thru 43)
61V (LH)
Caster Wheel Assembly (Incl. 31 thru 43)
61V (RH)
Caster Wheel Assembly (Incl. 31 thru 43)
72VS (LH)
Caster Wheel Assembly (Incl. 31 thru 43)
72VS (RH)
Grease Fitting
