LEGEND HYDRAULIC DIAGRAM
IN Water inlet F
1
Product flow meter
E
1
Filler solenoid valve P
2
Delivery minimum pressure switch
P
1
Filler pressure switch R Vat cock
FIL Filter - CARBONLOK 5 micron M2 Delivery pump
M1 Osmosis pump F
2
Waste flow meter
S
R
“Re-treatment” needle valve E
2
Discharge solenoid valve
VR Non-return valve SS Discharge choke
MP Pump pressure gauge VE Espansion tank
S
M
Mixer needle valve P
3
Delivery pressure switch
MO Osmosis membrane SC Water discarded
CO Conductivity meter PR Produced water
LEGEND ELECTRIC DIAGRAM
SA Anti flooding sensor IO Osmosis switch
CO Conductivity meter E
1
Filler solenoid valve
LR Red led E
2
Discharge solenoid valve
LV Green led M1 Osmosis pump
SE Electronic board LB Low level switch
M2 Delivery pump LA High level switch
P
3
Delivery pressure switch PB Low pressure switch
P
2
Delivery minimum pressure switch F
2
Waste flow meter
SS Shuko plug SE Selector
IR Delivery switch F
1
Product flow meter
