PARTS
-35-
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
1
XPW07
FLAT WASHER
5
⁄
16
"
2
XPB21
HEX BOLT
3
⁄
8
"-16 x
3
⁄
4
"
3
X1679003 MOTOR PULLEY
4
XPVA36
V-BELT A-36
5
XPK12M
KEY 5 x 5 x 30L
6
XPB03
HEX BOLT
5
⁄
16
"-18 x 1"
7
X1679007 CABINET STAND
8
X1679008 KNOB
3
⁄
8
"-16 x 1
1
⁄
2
"
9
XPN08
HEX NUT
3
⁄
8
"-16
10
XPWR810 WRENCH 8/10MM
11
X1679011 SWITCH BOX
12
X1679012 CONTROL PANEL
13
X1679013 FLEXIBLE WIRE(BLACK)
14
XPS01
PHLP HD SCREW 10-24 x
1
⁄
2
"
15
X1679015 MOTOR ON PILOT LIGHT
16
XPWRCRD110S
MOTOR CORD
17
X1679017 PHILLIPS HD FLANGE SCREW
18
XPN07
HEX NUT 10-24
19
X1679019 WIRE CONNECTOR
20
X1679020 NYLON CABLE TIE
21
XPS08
PHLP HD SCREW 10-24 x
3
⁄
4
"
22
X1679022 UPPER COLOR STRIPE
23
XPHTEK10
SELF TAPPING SCREW #4 x
3
⁄
8
"
24
XPN02
HEX NUT
5
⁄
16
"-18
25
XPCB01
CARRIAGE BOLT
5
⁄
16
"-18 x
5
⁄
8
"
26
XPW02
FLAT WASHER
3
⁄
8
"
27
XPSS03
SETSCREW
1
⁄
4
"-20 x
3
⁄
8
"
28
X1679028 MOTOR 1HP
29
XPB32
HEX BOLT
5
⁄
16
"-18 x
5
⁄
8
"
30
XPWRCRD110L
POWER CORD
31
X1679031 CABINET DOOR
32
X1679032 LATCH
33
XPW02
FLAT WASHER
3
⁄
8
"
34
XPAW03M ALLEN WRENCH 3MM
35
X1679035 PEDESTAL ARM
36
X1679036 FLEXIBLE WIRE(YELLOW)
37
X1679037 CABLE MARKER
38
X1679038 EMERGENCY STOP SWITCH
39
X1679039 ON SWITCH
40
X1679040 MAGNETIC SWITCH 110V
40A X1679040A
FRONT SWITCH COVER
40B
X1679040B
REAR SWITCH COVER
41
XPW03
FLAT WASHER #10
42
X1679042 STRAIN RELIEF
1
⁄
2
"
43
X1679043 CORD
44
X1679044 CABLE CLAMP
45
X1679045 BOTTOM COLOR STRIPE
46
X1679046 LOGO SHOP FOX
47
X1679047 MACHINE ID/WARNING LABEL
48
X1679048 ELECTRICITY LABEL
49
X1679049 SAFETY GLASSES LABEL
50
X1679050 READ MANUAL LABEL
51
X1679051 MAGNETIC SWITCH 220V
(OPTIONAL)
52
X1679052 WIRE GROMMET
53
W1001
DUST PORT
54
XPS38
PHLP HD SCR
5
⁄
16
"-18 X
1
⁄
2
"
101 X1679101 PIVOT STUD
1
⁄
2
"-20 x
3
⁄
4
"
102 X1679102 SPECIAL SCREW
3
⁄
8
"-16 x 1
1
⁄
2
"
103 X1679103 TILT LEVER
104 X1679104 SPECIAL SCREW
5
⁄
16
"-18 X 1
3
⁄
4
"
105 X1679105 FENCE STOP BRACKET
106 XPN19
HEX NUT
7
⁄
16
"-14
107 X1679107 FENCE TILT CLAMP
108 XPRP18M ROLL PIN 4 x 12L
109 X1679109 STOP TAB
110 X1679110 FENCE TILT SLEEVE
111 X1679111 LOCKING SCREW
1
⁄
2
"-12 X 3
3
⁄
4
"
112 XPN02
HEX NUT
5
⁄
16
"-18
113 X1679113 FENCE LOCK BRACKET
114 XPW06
FLAT WASHER
1
⁄
4
"
115 XPN01
HEX NUT
1
⁄
2
"-20
116 X1679116 FENCE
117 X1679117 FENCE HINGE
118 XPN08
HEX NUT
3
⁄
8
"-16
119 X1679119 KNOB
3
⁄
8
"
120 X1679120 FENCE BRACKET
121 X1679121 SPECIAL SCREW
5
⁄
16
"-18 X 1
1
⁄
4
"
122 X1679122 FENCE ADJUSTMENT ROD
123 X1679123 90º STOP
124 X1679124 SPECIAL BOLT
5
⁄
16
"-18 X
5
⁄
8
"
125 XPN09
HEX NUT
5
⁄
8
"-18
126 X1679126 FENCE BASE
127 XPB03
HEX BOLT
5
⁄
16
"-18 x 1"
128 XPB22
HEX BOLT
5
⁄
16
"-18 x 1
3
⁄
4
"
129 XPS07
PHLP HD SCREW
1
⁄
4
"-20 x
3
⁄
8
"
130 X1679130 SUPPORT
131 XPW01
FLAT WASHER
1
⁄
2
"
132 X1679132 SPECIAL NUT
1
⁄
2
"-12
