Splendide 5200 - Manual (Page 2)

To winterize your washer-dryer:
1. With the machine power OFF, pour ½ quart of RV-
type antifreeze into the washer drum
2. Close the door. Advance the Program Selector knob to
a SPIN position
3. Press ON/OFF Button (IN). Wait 1-2 minutes
4. Press ON/OFF Button (OUT). Unplug the washer-dryer
from the electrical outlet (or disconnect power)
5. Turn the water supply faucets OFF. Disconnect the
inlet hoses from the faucets. Drain any remaining
water from the hoses. Finished!
Optional RV Winterization - If you’re currently
pumping antifreeze through the fresh water
system, follow these steps to winterize:
1. With the machine power OFF, turn the WASH TEMP
knob to HOT
2. Advance the Program Selector knob to REGULAR in
Cotton Heavy Duty
3. Press the ON/OFF button (IN) and let the machine
fi ll until antifreeze is in the drum
4. Advance Program Selector to a RESET. Wait 5
seconds (Status/Door Lock LED will blink)
5. Advance Program Selector to a SPIN position. Let
the antifreeze drain from the drum
6. Advance Program Selector to RESET. Wait 5 seconds
(Status/Door Lock LED will blink)
7. Turn the WASH TEMP knob to COLD
8. Advance the Program Selector knob to REGULAR in
Cotton Heavy Duty
9. Let the machine fi ll until you see antifreeze in the
drum
10. Advance the Program Selector knob to RESET. Wait
5 seconds (Status/Door Lock LED will blink)
11. Advance the Program Selector knob to SPIN. Let the
antifreeze drain from the drum
12. Press the ON/OFF button (OUT). Finished!
To use again, fl ush the water pipes, then:
1. Reconnect the water inlet hoses to the correspond-
ing HOT/COLD faucets. Turn the faucets ON. (NOTE:
Check the water inlet hoses and pump periodically.
Refer to the “Use & Care Guide” that came with the
machine)
2. Plug the washer-dryer into an appropriate electrical
outlet (or reconnect power supply)
3. With the ON/OFF button in the off (OUT) position,
pour 1/2 TBSP. of powder detergent (or liquid
equiv.) into the ‘Detergent’ compartment inside the
Dispenser Drawer
4. Advance the Program Selector knob to an EXPRESS
cycle
5. Press the ON/OFF button (IN) and allow the
machine to run through the complete cycle to clean
out any remaining antifreeze. Finished!
M O D E L S
WD2000S (Splendide 2000S)
WD2100 (Splendide 2100)
WDC6200 CEE (Comb-o-matic 6200)
WDC5200 (Comb-o-matic 5200)
Front-Loading Washer-Dryer
Addendum to Owners Manual
Splendide
®
W A S H E R  D R Y E R
© C
op
yrigh
t 2004,
W
estland S
ales
, Clackamas
, OR 97015
Q U E S T I O N S ?
Splendide Service HQ:
Westland Sales
15650 SE 102nd Ave. (PO BOX 427)
Clackamas, OR 97015
Telephone: Toll Free: 800-356-0766
(Local: 503-655-2563)
Service Fax:
(503) 722-9202
E-mail: [email protected]
Website: www.splendide.com
W
I N T E R I Z A T I O N
S
U P P L E M E N T
To Open the Door During a Wash Cycle:
1. Advance the Program Selector to ‘Reset’ and wait 5
seconds.
2. Advance the Program Selector to ‘Drain’ (8 o’clock)
and allow the machine to drain completely.
3. Advance the Program Selector to ‘Reset’ (The ‘Status/
Door Lock’ LED will blink quickly to indicate that the
cycle has stopped, but the door is STILL LOCKED)
4. When the ‘Status/Door Lock’ LED blinks SLOWLY (takes
1-2 minutes), you can open the door
To Open the Door During a Dry Cycle:
1. Advance the Program Selector to ‘Reset’ (The ‘Status/
Door Lock’ LED will blink quickly to indicate the cycle
has stopped, but the door is STILL LOCKED)
2. When the ‘Status/Door Lock’ LED blinks SLOWLY
(takes 1-2 minutes), you can open the door
D
O O R
L
O C K
S
U P P L E M E N T
!
DO NOT DISCARD!
T
HIS INFORMATION
SUPERSEDES THE
INFORMATION FOUND IN
YOUR OWNERS MANUAL
KEEP THIS PAGE WITH YOUR
OWNERS MANUAL FOR
FUTURE REFERENCE
Once a wash or dry cycle is underway, the washer-dryer door will
LOCK for the duration of the cycle and will STAY LOCKED for up to 2
minutes after the cycle ends. DO NOT attempt to open the door unless
the ‘STATUS/DOOR LOCK’ LED is BLINKING SLOWLY!
IMPORT AN T ! !
Follow theses steps if you need to winterized your washer-dryer that’s installed in a boat or RV
Follow these steps if you need to open the door to your washer-dryer after a cycle has already begun
